Cannabis Extraction Chillers

Decades of Industrial Cooling Experience

Thermonics chillers originated as customized solutions for demanding applications within the Mil/Aero and Energy industries. Today, we have leveraged that engineering expertise to produce a family of chillers delivering the highest quality and fastest pull-down times available in the botanical extraction industry. Our cooling systems are ideal for large scale industrial cannabis manufacturing and small run, startup processing. We can help you get colder, faster to increase your cannabis processing throughput.

Chill 100 Gallons of Ethanol to -60°C in 40 Minutes

Cryogenic Cooling Solutions

Thermonics LN2-cooled chillers use liquid nitrogen and a proprietary cooling technology to rapidly chill ethanol during the extraction process. The chiller's small footprint and massive cooling capacity make it adaptable to cool a continuous, in-line flow or larger jacketed vessels.

• Cooling capacity up to 20kW @ -90.0°C
• Small footprint; low initial cost
• Programmable touch-screen and remote control
• On demand cooling: 150 gallons of ethanol per hour at -60°C

Chill 100 Gallons of Ethanol to -60°C in Under 120 Minutes

Compressor Based Cooling Solutions

Thermonics compressor-based extraction chillers use traditional mechanical refrigeration to chill hydrocarbons and solvents to low and ultra-low temperatures. These workhorse chillers are available in 18 different models with both air-cooled and water-cooled heat rejection and options for fluid pressure and flow control.

• -40°, -60° and -80°C, up to 14kW @ 0.0°C
• Recirculates heat transfer fluid to jacketed vessel
• Programmable touch screen controller

View Water Cooled Chiller Datasheets

Process Chiller W-40-1100

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The W-40-1100 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -40 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller W-40-1100

Process Chiller W-40-2000

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The W-40-2000 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -40 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller W-40-2000

Process Chiller W-40-3100

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The W-40-3100 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -40 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller W-40-3100

Process Chiller W-60-2800

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The W-60-2800 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -60 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller W-60-2800

Process Chiller W-60-3100

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The W-60-3100 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -60 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller W-60-3100

Process Chiller W-60-4700

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The W-60-4700 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -60 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller W-60-4700

Process Chiller W-80-600

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The W-80-600 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -80 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller W-80-600

Process Chiller W- 80-1800

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The W- 80-1800 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -80 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller W- 80-1800

Process Chiller W-80-2500

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The W-80-2500 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -80 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller W-80-2500

View Air Cooled Chiller Datasheets

Process Chiller A-40-1100

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The A-40-1100 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -40 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller A-40-1100

Process Chiller A-40-1900

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The A-40-1900 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -40 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller A-40-1900

Process Chiller A-40-2700

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The A-40-2700 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -40 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller A-40-2700

Process Chiller A-60-2700

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The A-60-2700 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -60 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller A-60-2700

Process Chiller A-60-3000

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The A-60-3000 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -60 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller A-60-3000

Process Chiller A-60-4600

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The A-60-4600 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -60 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller A-60-4600

Process Chiller A-80-500

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The A-80-500 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -80 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller A-80-500

Process Chiller A- 80-1700

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The A- 80-1700 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -80 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller A- 80-1700

Process Chiller A-80-2400

Thermonics specializes in the design and manufacture of low temperature standard and custom fluid chillers for challenging applications. The A-80-2400 FluidChill™ system delivers high reliability and precision temperature control.

Temperature Range: -80 to +50 °C

Stability: ±0.5 °C

Get the data sheet: Process Chiller A-80-2400

Notes:
1) Fluid pressure for all water-cooled and air-cooled models is 50 PSIG or less.
2) -40 and -60°C performance achieved with Syltherm XLT fluid. -80°C performance achieved with HFE-7100 fluid.
3) Consult factory for applications using other heat transfer fluids and flow rates.

Ethanol and Hydrocarbon Cooling Solutions for CBD and THC Extraction

Cooling Capacity up to
20kW at -90°C

High Reliability, USA Manufacturer, Worldwide Support

Decades of Industrial Cooling Experience
